Palram - Canopia Sydney Wave Single Carport (HG9095)

Palram - Canopia Sydney Wave Single Carport (HG9095)

Discover the Sydney Cantilever Carport, designed for seamless parking without additional posts. Perfect for turnaround areas and car charging stations, its innovative cantilever design maximizes space efficiency while providing robust vehicle protection. The versatile kit features panels that allow sunlight transmission with UV protection and ample shade, adaptable as a flat top carport, patio cover, or outdoor lounge area. Measuring nearly 10 feet wide by 20 feet long, this two-legged shelter is engineered to endure volatile weather conditions. Constructed with ultra-resilient polycarbonate, it includes an internal gutter and offers 4 inches more width than competitors. Safeguard your vehicle from snow, hail, wind, and UV rays with this modern and adaptable parking solution.

Before ordering, ensure compliance with local building and zoning codes, and obtain any necessary permits for a hassle-free installation.

Features:

• Versatile Cantilever Carport: The flat top carport has two massive (3 x 6.5 in) posts to optimize space with overhead clearance of 6'6"-9’5".
• Durable Structure: Aluminum frame is a strong, rust-resistant grey-coated metal and includes integrated rain gutters to direct rainwater.
• Resilient Panels: Polycarbonate is 100% UV protected, virtually unbreakable and does not turn yellow or become brittle over time. No need to remove panels for Winter.
• UV Protection: The corrugated solar grey polycarbonate panels provide 10% light transmission, protecting your vehicles from strong sunlight exposure.
• Year-Round Weather Resistance: Wind, snow, and hail resistant. Tested to withstand winds up to 75 mph and 15 lb./ft² of snow.
• Self-Assembly: Easy sliding panel system includes pre-drilled profiles and pre-cut panels making assembly as simple as possible. Concrete footing required for installation.
• Warranty: 10 Year Limited Warranty. Customers are responsible for ensuring a perfectly flat, level surface site for construction.

Specifications:

Dimensions: 231.1 L x 112.6 W x 113.4 H
Side Wall: 78.7"
Total Product Weight: 489.51 lbs
Snow Load: 13.31 psf
Wind Load: 75 mph
Light Transmission (%): 10
Roof Material: 0.7mm Polycarbonate
Roof Color: Gray
Frame Material: Aluminum
Frame Color: Black

SHIPPING

Curbside Tailgate Delivery – No Lift Gate Service

A type of LTL Freight delivery most commonly used by carriers for oversized freight that cannot fit on a lift gate.

For this type of delivery, customers are required to prepare at least 2–3 people to assist with unloading. If the item is too heavy, the cartons can be unstrapped from the pallet and carried one by one. If they are still too heavy, the cartons can be opened at the end and larger pieces can be slid out to lighten the load.

The drop-off point is at the street level, as shown in the image BELOW.
